Joseph Giles - Sliding door traditional key deadlock

This sliding door look is recessed into the door and its deadbolt is operated by a traditional 3 lever-style key. When the key is turned, the bolt splays out sideways.

When installing these locks, please ensure that the cut-out in the frame for the bolt is wide enough for the splayed-out deadbolt. These locks are keyed to differ as standard, meaning that each key is individual for each lock. They can also be supplied keyed alike if required.

These locks are not compatible with dust boxes or rebate kits.

Minimum door thickness for these locks is 32mm and the maximum, as standard, is 70mm.

Includes:

• Lock case (The actual lock)
• Forend (Plate that goes over the end of the lock)
• Strike plate (Plate that is fitted to the frame)
• Fixing pack
• 2 keys

For up-to-date Dimensions & Technical Help Sheets on this item please visit the Joseph Giles UK website and search LA1001. You will need to create an account to login. Alternatively, contact our helpful sales consultants for assistance.
